E-SPACE 8.4 28″

EcoLogic 45Nm/Speed Smart
System EcoLogic

Blue Navy/Flat Grey Matt

Telaio	Alu. 700c, easy access, integrated battery, integrated HT, disc brake, internal cables
Forcella	Suntour NEX 700c, alu with alu crown, 50mm o Zoom 187D, 29”, 65mm, Coil White
Serie sterzo	FSA integrated 1”1/8
Guarnitura	Byte alu 42T cartridge
Cambio	Shimano Altus RD-M310
Comandi	Hydraulic disk, Rotor 160 mm, with brake lever switch
Freni	Shimano Tourney SL-RS45 RevoShift, 8s
Ruota Libera	DNP 8s 13-28
Pedali	Resin antislip
Mozzi	Shimano quick release front, motor on rear, 36h, INT
Cerchi	Beretta 700c, double wall w/eylets, 36h, disc
Attacco manubrio	Byte alu over, ahead, adjustable
Piega manubrio	Byte alu over
Reggisella	Byte alu with clamp, 27,2mm
Sella	Selle Royal Aurorae w/elastomer
Coperture	Byte Trento 700x45c, with reflecting line
Parafanghi	Single stay speedy
Copricatena	Plastic, L type
Portapacchi	Rear alu 14mm with spring, 25kg load
Luci esterne	Axa front (15 lux) and rear LED, controlled by display
Taglia	45
Colore	Blue Navy/Flat Grey Matt
Note	kickstand Ursus adjustable, bell

Coppia massima	45 Nm
Tipo sensore	Speed sensor w/12 pulses
Batteria	504
Tipo caricabatteria	2A Europlug
Tempo di ricarica	100%: 8h16 / 80%: 6h16m
Velocità max assistita	25km/h
Display	Atala A10 LCD Smart CAN, with remote control
Potenza	5 levels, Speed/Torque adjust
Altre funzioni	Soft start: 0 - 6km/h, with no pedalingExternal light controlSpeed informationBattery information
