E-RUN 7.1 FS MAN 500

EcoLogic 35Nm/Speed
System EcoLogic

Black/Neon Red Matt

Telaio	Alu. 700c, internal cables
Forcella	HL CH-187 700c, alu with alu crown, 40mm
Serie sterzo	Steel 1”1/8, threaded, with cap
Guarnitura	Byte steel 42T cartridge, with cap
Cambio	Shimano Tourney RD-TY300 / LT
Comandi	Shimano Tourney SL-RS35 RevoShift, 7s / LT 7s
Freni	Promax alu, V-Brake, with brake lever switch
Pacco pignoni	Shimano Tourney 7s 14-28 / LT
Pedali	Resin City
Mozzi	Alu 36h, Shimano front, motor on rear
Cerchi	Beretta 700c alu, double wall w/eylets, 36h
Attacco manubrio	Byte alu, adjustable
Piega manubrio	Byte steel TKK
Reggisella	Byte alu with clamp, 27,2mm
Sella	Selle Royal Wave
Coperture	Byte Trento 700x45c
Parafanghi	Single stay speedy
Copricatena	Steel painted, L type
Portapacchi	Battery rear carrier with spring, 25kg
Luci esterne	Axa front (15 lux) and rear LED on battery, controlled by display
Taglia	49
Colore	Black/Neon Red Matt
Note	kickstand Ursus adjustable, bell, wheel reflectors

Coppia massima	35Nm
Tipo sensore	Speed sensor w/12 pulses
Batteria	518
Tipo caricabatteria	2A Europlug
Tempo di ricarica	100%: 7h30m / 80%: 5h40m
Velocità max assistita	25km/h
Display	Atala A15 LED UART
Potenza	5 levels, Speed/Torque adjust
Altre funzioni	Soft start: 0 - 6km/h, with no pedalingExternal light control
